XINJE XD3 Series Standard PLC 16 24 32 48 60 points model R-E/C T--E/C RT-E/C all model

 This item include:
   1Pcs PLC(According to the model you choose)


  XINJE XD3 Series Standard PLC
    Including 16, 24, 32, 48 and 60 points models. It has complete functions and can meet the needs of most users.

  XINJE XD3 Series Product Features
    XD3 series standard PLC, including 16, 24, 32, 48 and 60 points models.
    It has complete functions and can meet the needs of most users.
    The speed and capacity are greatly improved compared with XC series
    Input type: NPN
    Output type: Transistor (T), relay (R)
    Power specification: AC220V
    Support X-NET fieldbus function
    Support high-speed counting (up to 80kHz), pulse output (up to 100kHz), frequency measurement and other special functions
    Standard USB port for programming download
    Support 1 ~ 10 expansion modules, 1 expansion ed and 1 ~ 2 expansion BD (16 points are not supported)

  XD3-16R-C
    The host has 8 inputs/8 outputs, relay output, power supply DC24V, 2-way AB phase count, faster processing speed than XC series, DC24V output rated current 200mA;
  XD3-16R-E
    The host has 8 inputs/8 outputs, relay output, power supply AC100～240V, 2-way AB-phase counting, faster processing speed than XC series, DC24V output rated current 200mA;
  XD3-16RT-C
    The host has 8 inputs/8 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply DC24V, 2 AB phase counts, 2 high-speed pulses, faster processing speed than XC series, DC24V output rated current 200mA;
  XD3-16RT-E
    The host has 8 inputs/8 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply AC100～240V, 2 AB phase counts, 2 high-speed pulses, faster processing speed than XC series, standard clock, DC24V output Rated current 200mA;
  XD3-16T-C
    Host 8 inputs/8 outputs, transistor output, power supply DC24V, 2-way AB-phase counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 200mA;
  XD3-16T-E
    Host 8 inputs/8 outputs, transistor output, power supply AC100～240V, 2-way AB-phase counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 200mA;
  XD3-24R-C
    Host 14 in/10 out, relay output, power supply DC24V, 3-way AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-24R-E
    Host 14 in/10 out, relay output, power supply AC100~240V, 3-way AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-24RT-C
    The host has 14 inputs/10 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply DC24V, 3 AB-phase high-speed counting, 2 high-speed pulses, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-24RT-E
    The host has 14 inputs/10 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply AC100～240V, 3 AB-phase high-speed counting, 2 high-speed pulses, faster processing speed than XC series, DC24V output rated current 400mA ;
  XD3-24T-C
    Host 14 in/10 out, transistor output, power supply DC24V, 3-way AB-phase high-speed counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-24T-E
    Host 14 in/10 out, transistor output, power supply AC100~240V, 3-way AB-phase high-speed counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32R-C
    Host 18 in/14 out, relay output, power supply DC24V, 3-way AB phase count, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32R-E
    Host 18 in/14 out, relay output, power supply AC100~240V, 3-way AB phase count, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32RT-C
    The host has 18 inputs/14 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply DC24V, 3 AB phase counting, 2 high-speed pulses, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32RT-E
    The host has 18 inputs/14 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply AC100～240V, 3 AB phase counts, 2 high-speed pulses, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32T-C
    Host 18 in/14 out, transistor output, power supply DC24V, 3-way AB-phase counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-32T-E
    Host 18 in/14 out, transistor output, power supply AC100~240V, 3-way AB-phase counting, 2-way high-speed pulse, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-48R-C
    Host 28 in/20 out, relay output, power supply DC24V, 3-way AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-48R-E
    Host 28 in/20 out, relay output, power supply AC100~240V power supply, 3-way AB-phase high-speed counting, faster processing speed than XC series, standard clock, DC24V output rated current 400mA;
  XD3-48RT-C
    The host has 28 inputs/20 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply DC24V, 2 pulse outputs, 3 AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-48RT-E
    The host has 28 inputs/20 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply AC100～240V, 2 pulse outputs, 3 AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA ;
  XD3-48T-C
    Host 28 in/20 out, transistor output, power supply DC24V, 2-channel pulse output, 3-channel AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-48T-E
    Host 28 in/20 out, transistor output, power supply AC100~240V, 2-channel pulse output, 3-channel AB-phase high-speed counting, faster processing speed than XC series, standard clock, DC24V output rated current 400mA;
  XD3-60R-C
    Host 36 in/24 out, relay output, power supply DC24V, 3-way AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-60R-E
    Host 36 in/24 out, relay output, power supply AC100~240V, 3-way AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-60RT-C
    The host has 36 inputs/24 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply DC24V, 2 pulse outputs, 3 AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-60RT-E
    The host has 36 inputs/24 outputs, the first 2 transistor outputs, the remaining relay outputs, the power supply AC100～240V, 2 pulse outputs, 3 AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA ;
  XD3-60T-C
    Host 36 in/24 out, transistor output, power supply DC24V, 3-way AB-phase high-speed counting, 2-way pulse output, faster processing speed than XC series, DC24V output rated current 400mA;
  XD3-60T-E
    Host 36 in/24 out, transistor output, power supply AC100~240V, 2-channel pulse output, 3-channel AB-phase high-speed counting, faster processing speed than XC series, DC24V output rated current 400mA;
